TT03+02 BCTT 50M
- Inner diameter:
- 50 mm
- Mass:
- 13 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - TT03+02 BCTT 50M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
TT03
Bearing model :
02 BCTT 50M
Bore :
50 mm
Length guidance groove (b) :
128 mm
Hight (W) :
235 mm
Distance between the bottom of the guide (D) :
203 mm
Distance from mounting hole to center line of housing (A) :
146 mm
Length total (a) :
280 mm
Pin diameter (X) :
24 mm
Distance from center line to end of housing (V) :
102 mm
Distance from the center line of the bearing seat to the shaft insertion end (K) :
35 mm
Mounting step (P) :
20 mm
Distance from mounting hole to step (H) :
32 mm
Guide groove width (O) :
30 mm
Distance from guidance groove to end face (R) :
29 mm
Housing width (L) :
114 mm
Weight :
13 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Take-up Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Bore,
Length guidance groove (b),
Hight (W),
Distance between the bottom of the guide (D),
Distance from mounting hole to center line of housing (A),
Length total (a),
Pin diameter (X),
Distance from center line to end of housing (V),
Distance from the center line of the bearing seat to the shaft insertion end (K),
Mounting step (P),
Distance from mounting hole to step (H),
Guide groove width (O),
Distance from guidance groove to end face (R),
Housing width (L),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Bore,
Length guidance groove (b),
Hight (W),
Distance between the bottom of the guide (D),
Distance from mounting hole to center line of housing (A),
Length total (a),
Pin diameter (X),
Distance from center line to end of housing (V),
Distance from the center line of the bearing seat to the shaft insertion end (K),
Mounting step (P),
Distance from mounting hole to step (H),
Guide groove width (O),
Distance from guidance groove to end face (R),
Housing width (L),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - TT03+02 BCTT 50M Split Bearing Units Advantages and Applications
QIBR - TT03+02 BCTT 50M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
