Polyurethane Coated Bearing With Screw

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner ring diameter

3mm-25mm

Outer ring diameter

8mm-70mm

Width

3mm-20mm

Dynamic radial load

5lbf-1888lbf

Material

NDI/POM Polyurethane

Basic static load rating,radial

2lbf-1059lbf

MAX speed

7.8-42.6(X1000 rpm)

Brand

QIBR/OEM/Neutral

Polyurethane Coated Bearing With Screw

Filters

NO. Product Product Number Ball material Outer diameter (D) Ring material Screw length Shield material Width
1 6203 6203 2rs Chrome Steel 50 mm Chrome Steel 12 mm NBR 18 mm
2 6203 6203 2rs Chrome Steel 60 mm Chrome Steel 12 mm NBR 18 mm
3 623 623 2rs Chrome Steel 15 mm Chrome Steel 5 mm NBR 4 mm
4 624 624 2rs Chrome Steel 15 mm Chrome Steel 5 mm NBR 5 mm
5 624 624 2rs Chrome Steel 30 mm Chrome Steel 5 mm NBR 5 mm
6 683 683 2rs Chrome Steel 10 mm Chrome Steel 4 mm NBR 3 mm
7 683 683 2rs Chrome Steel 12 mm Chrome Steel 4 mm NBR 3 mm
8 693 693 2rs Chrome Steel 10 mm Chrome Steel 5 mm NBR 4 mm
9 693 693 2rs Chrome Steel 10 mm Chrome Steel 5 mm NBR 5 mm
10 693 693 2rs Chrome Steel 10 mm Chrome Steel 4 mm NBR 5 mm
11 693 693 2rs Chrome Steel 10 mm Chrome Steel 5 mm NBR 6 mm
12 MR63 MR63 2rs Chrome Steel 8 mm Chrome Steel 4 mm NBR 3 mm
13 604 604 2rs Chrome Steel 16 mm Chrome Steel 6 mm NBR 5 mm
14 684 684 2rs Chrome Steel 11 mm Chrome Steel 5 mm NBR 4 mm
15 684 684 2rs Chrome Steel 13 mm Chrome Steel 5 mm NBR 4 mm
16 684 684 2rs Chrome Steel 13 mm Chrome Steel 5 mm NBR 8 mm
17 684 684 2rs Chrome Steel 14 mm Chrome Steel 5 mm NBR 6 mm
18 605 605 2rs Chrome Steel 18 mm Chrome Steel 6 mm NBR 5 mm
19 605 605 2rs Chrome Steel 19 mm Chrome Steel 6 mm NBR 7 mm
20 625 625 2rs Chrome Steel 20 mm Chrome Steel 6 mm NBR 5 mm
21 625 625 2rs Chrome Steel 22 mm Chrome Steel 8 mm NBR 7 mm
22 625 625 2rs Chrome Steel 22 mm Chrome Steel 8 mm NBR 9 mm
23 625 625 2rs Chrome Steel 24 mm Chrome Steel 6 mm NBR 5 mm
24 625 625 2rs Chrome Steel 25 mm Chrome Steel 8 mm NBR 9 mm
25 685 685 2rs Chrome Steel 16 mm Chrome Steel 6 mm NBR 5 mm
26 685 685 2rs Chrome Steel 17 mm Chrome Steel 8 mm NBR 10 mm
27 685 685 2rs Chrome Steel 16 mm Chrome Steel 6 mm NBR 8 mm
28 606 606 2rs Chrome Steel 21 mm Chrome Steel 8 mm NBR 9 mm
29 606 606 2rs Chrome Steel 22 mm Chrome Steel 8 mm NBR 6 mm
30 606 606 2rs Chrome Steel 24 mm Chrome Steel 8 mm NBR 6 mm
31 626 626 2rs Chrome Steel 24 mm Chrome Steel 8 mm NBR 8 mm
32 626 626 2rs Chrome Steel 26 mm Chrome Steel 8 mm NBR 10 mm
33 626 626 2rs Chrome Steel 26 mm Chrome Steel 8 mm NBR 12 mm
34 626 626 2rs Chrome Steel 26 mm Chrome Steel 8 mm NBR 8 mm
35 626 626 2rs Chrome Steel 28 mm Chrome Steel 8 mm NBR 13 mm
36 626 626 2rs Chrome Steel 28 mm Chrome Steel 8 mm NBR 6 mm
37 626 626 2rs Chrome Steel 30 mm Chrome Steel 8 mm NBR 10 mm
38 626 626 2rs Chrome Steel 30 mm Chrome Steel 8 mm NBR 12 mm
39 626 626 2rs Chrome Steel 30 mm Chrome Steel 8 mm NBR 6 mm
40 626 626 2rs Chrome Steel 30 mm Chrome Steel 8 mm NBR 9 mm
41 626 626 2rs Chrome Steel 33 mm Chrome Steel 8 mm NBR 7 mm
42 626 626 2rs Chrome Steel 35 mm Chrome Steel 8 mm NBR 14 mm
43 626 626 2rs Chrome Steel 40 mm Chrome Steel 8 mm NBR 10 mm
44 696 696 2rs Chrome Steel 18 mm Chrome Steel 8 mm NBR 7 mm
45 696 696 2rs Chrome Steel 18 mm Chrome Steel 8 mm NBR 7 mm
46 696 696 2rs Chrome Steel 20 mm Chrome Steel 12 mm NBR 5 mm
47 696 696 2rs Chrome Steel 20 mm Chrome Steel 8 mm NBR 6 mm
48 696 696 2rs Chrome Steel 20 mm Chrome Steel 8 mm NBR 8 mm
49 696 696 2rs Chrome Steel 22 mm Chrome Steel 12 mm NBR 5 mm
50 696 696 2rs Chrome Steel 22 mm Chrome Steel 8 mm NBR 5 mm
51 608 608 2rs Chrome Steel 24 mm Chrome Steel 8 mm NBR 7 mm
52 608 608 2rs Chrome Steel 26 mm Chrome Steel 8 mm NBR 7 mm
53 608 608 2rs Chrome Steel 28 mm
