Polyurethane Coated Bearing

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner diameter

1.5mm-25mm

Outer diameter

7mm-80mm

Width

3mm-36mm

Dynamic radial load

2lbf-1888lbf

Coated material

NDI/POM Polyurethane

Static load rating,radial

1lbf-1059lbf

MAX speed

7.8-78 (X1000 rpm)

Brand

QIBR/OEM/Neutral

Polyurethane Coated Bearing

Filters

NO. Product Product Number Bore Inner ring type Outer diameter (D) Seal type Shield material Width
1 6817 6817 2rs 1.5 mm Normal 7 mm Sealed NBR 4 mm
2 6818 6818 2rs 1.5 mm Normal 8 mm Sealed NBR 4 mm
3 6203 6203 2rs 17 mm Normal 50 mm Sealed NBR 18 mm
4 6203 6203 2rs 17 mm Normal 60 mm Sealed NBR 18 mm
5 6903 6903 2rs 17 mm Normal 40 mm Sealed NBR 10 mm
6 683 683 2rs 3mm Normal 10 mm Sealed NBR 3 mm
7 683 683 2rs 3 mm Normal 12 mm Sealed NBR 3 mm
8 693 693 2rs 3 mm Normal 10 mm Sealed NBR 4 mm
9 693 693 2rs 3 mm Normal 10 mm Sealed NBR 5 mm
10 693 693 2rs 3 mm Normal 12 mm Sealed NBR 4 mm
11 604 604 2rs 4 mm Normal 16 mm Sealed NBR 5 mm
12 624 624 2rs 4 mm Normal 15 mm Sealed NBR 5 mm
13 624 624 2rs 4 mm Normal 18 mm Sealed NBR 5 mm
14 624 624 2rs 4 mm Normal 30 mm Sealed NBR 5 mm
15 684 684 2rs 4 mm Normal 11 mm Sealed NBR 4 mm
16 684 684 2rs 4 mm Normal 12 mm Sealed NBR 4 mm
17 684 684 2rs 4 mm Normal 12 mm Sealed NBR 6 mm
18 684 684 2rs 4 mm Normal 13 mm Sealed NBR 4 mm
19 684 684 2rs 4 mm Normal 13 mm Sealed NBR 8 mm
20 684 684 2rs 4 mm Normal 14 mm Sealed NBR 6 mm
21 605 605 2rs 5 mm Normal 18 mm Sealed NBR 5 mm
22 605 605 2rs 5 mm Normal 19 mm Sealed NBR 7 mm
23 605 605 2rs 5 mm Normal 21 mm Sealed NBR 8 mm
24 625 625 2rs 5 mm Normal 20 mm Sealed NBR 5 mm
25 625 625 2rs 5 mm Normal 22 mm Sealed NBR 5 mm
26 625 625 2rs 5 mm Normal 22 mm Sealed NBR 7 mm
27 625 625 2rs 5 mm Normal 22 mm Sealed NBR 9 mm
28 625 625 2rs 5 mm Normal 24 mm Sealed NBR 5 mm
29 625 625 2rs 5 mm Normal 25 mm Sealed NBR 9 mm
30 685 685 2rs 5 mm Normal 16 mm Sealed NBR 5 mm
31 685 685 2rs 5 mm Normal 16 mm Sealed NBR 8 mm
32 685 685 2rs 5 mm Normal 17 mm Sealed NBR 10 mm
33 695 695 2rs 5 mm Normal 18 mm Sealed NBR 5 mm
34 606 606 2rs 6 mm Normal 21 mm Sealed NBR 9 mm
35 606 606 2rs 6 mm Normal 22 mm Sealed NBR 6 mm
36 606 606 2rs 6 mm Normal 24 mm Sealed NBR 6 mm
37 626 626 2rs 6 mm Normal 24 mm Sealed NBR 24 mm
38 626 626 2rs 6 mm Normal 25 mm Sealed NBR 18 mm
39 626 626 2rs 6 mm Normal 26 mm Sealed NBR 10 mm
40 626 626 2rs 6 mm Normal 26 mm Sealed NBR 12 mm
41 626 626 2rs 6 mm Normal 26 mm Sealed NBR 8 mm
42 626 626 2rs 6 mm Normal 28 mm Sealed NBR 13 mm
43 626 626 2rs 6 mm Normal 28 mm Sealed NBR 6 mm
44 626 626 2rs 6 mm Normal 30 mm Sealed NBR 10 mm
45 626 626 2rs 6 mm Normal 30 mm Sealed NBR 12 mm
46 626 626 2rs 6 mm Normal 30 mm Sealed NBR 9 mm
47 626 626 2rs 6 mm Normal 33 mm Sealed NBR 7 mm
48 626 626 2rs 6 mm Normal 35 mm Sealed NBR 14 mm
49 626 626 2rs 6 mm Normal 40 mm Sealed NBR 10 mm
50 696 696 2rs 6 mm Normal 18 mm Sealed NBR 7 mm
51 696 696 2rs 6 mm Normal 19 mm Sealed NBR 5 mm
52 696 696 2rs 6 mm Normal 20 mm Sealed NBR 5 mm
53 696 696 2rs 6 mm Normal 20 mm Sealed NBR 6 mm
54 696 696 2rs 6 mm Normal 20 mm Sealed NBR 8 mm
55 696 696 2rs 6 mm Normal 22 mm Sealed NBR 5 mm
56 696 696 2rs 6 mm Normal 22 mm Sealed NBR 7 mm
57 608 608 2rs 8 mm Normal 24 mm Sealed NBR 7 mm
58 608 608 2rs 8 mm Normal 26 mm Sealed NBR 7 mm
59 608 608 2rs 8 mm Normal 28 mm Sealed NBR 10 mm
60 608 608 2rs 8 mm Normal 28 mm Sealed NBR 7 mm
61 608 608 2rs 8 mm Normal 28 mm Sealed NBR 8 mm
62 608 608 2rs 8 mm Normal 30 mm Sealed NBR 11 mm
63 608 608 2rs 8 mm Normal 30 mm Sealed NBR 7 mm
64 608 608 2rs 8 mm Normal 30 mm Sealed NBR 9 mm
65 608 608 2rs 8 mm Normal 32 mm Sealed NBR 10 mm
66 608 608 2rs 8 mm Normal 32 mm Sealed NBR 12 mm
67 608 608 2rs
