Single row cylindrical roller bearing

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

52100、100Cr6、SUJ2

Inner diameter (d)

30-95mm

Outer diameter (D)

55-145mm

Mass

0.13-1.4kg

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

Spinspindle of large motors,Machine tool spindle

Single row cylindrical roller bearing

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Radial dynamic load Static load rating,radial Weight Width (B)
1 N1006MR1KR/ N1006MR1KR 30 mm 55 mm 19.7 KN 19.6 KN 0.135 kg 13 mm
2 N1006MR1/ N1006MR1 30 mm 55 mm 19.7 KN 19.6 KN 0.135 kg 13 mm
3 N1007MRKR/ N1007MRKR 35 mm 62 mm 26.0 KN 23.2 KN 0.172 kg 14 mm
4 N1007MR/ N1007MR 35 mm 62 mm 26.0 KN 23.2 KN 0.172 kg 14 mm
5 N1008MRKR/ N1008MRKR 40 mm 68 mm 31.5 KN 29.0 KN 0.213 kg 15 mm
6 N1008MR/ N1008MR 40 mm 68 mm 31.5 KN 29.0 KN 0.213 kg 15 mm
7 N1009MRKR/ N1009MRKR 45 mm 75 mm 37.5 KN 35.5 KN 0.279 kg 16 mm
8 N1009MR/ N1009MR 45 mm 75 mm 37.5 KN 35.5 KN 0.279 kg 16 mm
9 N1009RSTPKR/ N1009RSTPKR 45 mm 75 mm 26.9 KN 29.4 KN 0.243 kg 16 mm
10 N1009RSTP/ N1009RSTP 45 mm 75 mm 26.9 KN 29.4 KN 0.243 kg 16 mm
11 N1009RXTPKR/ N1009RXTPKR 45 mm 75 mm 26.9 KN 29.4 KN 0.243 kg 16 mm
12 N1009RXTP/ N1009RXTP 45 mm 75 mm 26.9 KN 29.4 KN 0.243 kg 16 mm
13 N1009RSZTPKR/ N1009RSZTPKR 45 mm 75 mm 16.0 KN 14.7 KN 0.224 kg 16 mm
14 N1009RSZTP/ N1009RSZTP 45 mm 75 mm 16.0 kN 14.7 kN 0.224 kg 16 mm
15 N1009RXZTPKR/ N1009RXZTPKR 45 mm 75 mm 16.0 KN 14.7 KN 0.224 kg 16 mm
16 N1009RXZTP/ N1009RXZTP 45 mm 75 mm 16.0 KN 14.7 KN 0.224 kg 16 mm
17 N1010MRKR/ N1010MRKR 50 mm 80 mm 37.0 KN 36.0 KN 0.286 kg 16 mm
18 N1010MR/ N1010MR 50 mm 80 mm 37.0 KN 36.0 KN 0.286 kg 16 mm
19 N1010RSTPKR/ N1010RSTPKR 50 mm 80 mm 28.8 KN 33.0 KN 0.265 kg 16 mm
20 N1010RSTP/ N1010RSTP 50 mm 80 mm 28.8 KN 33.0 KN 0.265 kg 16 mm
21 N1010RXTPKR/ N1010RXTPKR 50 mm 80 mm 28.8 KN 33.0 KN 0.265 kg 16 mm
22 N1010RXTP/ N1010RXTP 50 mm 80 mm 28.8 KN 33.0 KN 0.265 kg 16 mm
23 N1010RSZTPKR/ N1010RSZTPKR 50 mm 80 mm 17.1 KN 16.5 KN 0.244 kg 16 mm
24 N1010RSZTP/ N1010RSZTP 50 mm 80 mm 17.1 KN 16.5 KN 0.244 kg 16 mm
25 N1010RXZTPKR/ N1010RXZTPKR 50 mm 80 mm 17.1 KN 16.5 KN 0.244 kg 16 mm
26 N1010RXZTP/ N1010RXZTP 50 mm 80 mm 17.1 KN 16.5 KN 0.244 kg 16 mm
27 N1011BMR1KR/ N1011BMR1KR 55 mm 90 mm 43.5 KN 44.0 KN 0.425 kg 18 mm
28 N1011BMR1/ N1011BMR1 55 mm 90 mm 43.5 KN 44.0 KN 0.425 kg 18 mm
29 N1011RSTPKR/ N1011RSTPKR 55 mm 90 mm 35.0 KN 39.5 KN 0.383 kg 18 mm
30 N1011RSTP/ N1011RSTP 55 mm 90 mm 35.0 KN 39.5 KN 0.383 kg 18 mm
31 N1011RXTPKR/ N1011RXTPKR 55 mm 90 mm 35.0 KN 39.5 KN 0.383 kg 18 mm
32 N1011RXTP/ N1011RXTP 55 mm 90 mm 35.0 KN 39.5 KN 0.383 kg 18 mm
33 N1011RSZTPKR/ N1011RSZTPKR 55 mm 90 mm 20.7 KN 19.7 KN 0.355 kg 18 mm
34 N1011RSZTP/ N1011RSZTP 55 mm 90 mm 20.7 KN 19.7 KN 0.355 kg 18 mm
35 N1011RXZTPKR/ N1011RXZTPKR 55 mm 90 mm 20.7 KN 19.7 KN 0.355 kg 18 mm
36 N1011RXZTP/ N1011RXZTP 55 mm 90 mm 20.7 KN 19.7 KN 0.355 kg 18 mm
37 N1012BMR1KR/ N1012BMR1KR 60 mm 95 mm 46.0 KN 48.5 KN 0.454 kg 18 mm
38 N1012BMR1/ N1012BMR1 60 mm 95 mm 46.0 KN 48.5 KN 0.454 kg 18 mm
39 N1012RSTPKR/ N1012RSTPKR 60 mm 95 mm 37.5 KN 44.0 KN 0.411 kg 18 mm
40 N1012RSTP/ N1012RSTP 60 mm 95 mm 37.5 KN 44.0 KN 0.411 kg 18 mm
41 N1012RXTPKR/ N1012RXTPKR 60 mm 95 mm 37.5 KN 44.0 KN 0.411 kg 18 mm
42 N1012RXTP/ N1012RXTP 60 mm 95 mm 37.5 KN 44.0 KN 0.411 kg 18 mm
43 N1012RSZTPKR/ N1012RSZTPKR 60 mm 95 mm 22.2 KN 22.1 KN 0.380 kg 18 mm
44 N1012RSZTP/ N1012RSZTP 60 mm 95 mm 22.2 KN 22.1 KN 0.380 kg 18 mm
45 N1012RXZTPKR/ N1012RXZTPKR 60 mm 95 mm 22.2 KN 22.1 KN 0.380 kg 18 mm
46 N1012RXZTP/ N1012RXZTP 60 mm 95 mm 22.2 KN 22.1 KN 0.380 kg 18 mm
47 N1013BMR1KR/ N1013BMR1KR 65 mm 100 mm 47.0 KN 51.0 KN 0.483 kg 18 mm
48 N1013BMR1/ N1013BMR1 65 mm 100 mm 47.0 KN 51.0 KN 0.483 kg 18 mm
49 N1013RSTPKR/ N1013RSTPKR 65 mm 100 mm 39.5 KN 49.5 KN 0.440 kg 18 mm
50 N1013RSTP/ N1013RSTP 65 mm 100 mm 39.5 KN 49.5 KN 0.440 kg 18 mm
51 N1013RXTPKR/ N1013RXTPKR 65 mm 100 mm 39.5 KN 49.5 KN 0.440 kg 18 mm
52 N1013RXTP/ N1013RXTP 65 mm 100 mm 39.5 KN 49.5 KN 0.440 kg 18 mm
53 N1013RSZTPKR/ N1013RSZTPKR 65 mm 100 mm 23.6 KN 24.5 KN 0.406 kg 18 mm
54 N1013RSZTP/ N1013RSZTP 65 mm 100 mm 23.6 KN 24.5 KN 0.406 kg 18 mm
55 N1013RXZTPKR/ N1013RXZTPKR 65 mm 100 mm 23.6 KN 24.5 KN 0.406 kg 18 mm
56 N1013RXZTP/ N1013RXZTP 65 mm 100 mm 23.6 KN 24.5 KN 0.406 kg 18 mm
57 N1014BMR1KR/ N1014BMR1KR 70 mm 110 mm 57.5 KN 63.0 KN 0.668 kg 20 mm
58 N1014BMR1/ N1014BMR1 70 mm 110 mm 57.5 KN 63.0 KN 0.668 kg 20 mm
