P37+02 B 280M
- Inner diameter:
- 280 mm
- Mass:
- 292.0 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - P37+02 B 280M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
P37
Bearing model :
02 B 280M
Inner diameter (d) :
280 mm
Distance shaft axis (H) :
378 mm
MIN distance fixing bore (E) :
514 mm
MAX distance fixing bore (E) :
554 mm
Distance fixing bore (e) :
101 mm
Distance fixing bore (S) :
254 mm
Number of mounting holes (n) :
8
Bolt size :
M30
Length total (a) :
914 mm
Width (base) (b) :
330 mm
Heigth (base) (g) :
60 mm
Hight (W) :
760 mm
Weight :
292.0 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Plummer Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (e),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (e),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - P37+02 B 280M Split Bearing Units Advantages and Applications
QIBR - P37+02 B 280M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
