P21+01 B 400M
- Inner diameter:
- 400 mm
- Mass:
- 309.0 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - P21+01 B 400M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
P21
Bearing model :
01 B 400M
Inner diameter (d) :
400 mm
Distance shaft axis (H) :
432 mm
MIN distance fixing bore (E) :
704 mm
MAX distance fixing bore (E) :
744 mm
Distance fixing bore (S) :
166 mm
Number of mounting holes (n) :
4
Bolt size :
M36
Length total (a) :
940 mm
Width (base) (b) :
254 mm
Heigth (base) (g) :
67 mm
Hight (W) :
865 mm
Weight :
309.0 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Plummer Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - P21+01 B 400M Split Bearing Units Advantages and Applications
QIBR - P21+01 B 400M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
