P32+02 B 607
- Inner diameter:
- 6 7/16 inch
- Mass:
- 106.0 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - P32+02 B 607
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Imperial
Housing model :
P32
Bearing model :
02 B 607
Inner diameter (d) :
6 7/16 inch
Distance shaft axis (H) :
267 mm
MIN distance fixing bore (E) :
428 mm
MAX distance fixing bore (E) :
468 mm
Distance fixing bore (S) :
172 mm
Number of mounting holes (n) :
4
Bolt size :
M30
Length total (a) :
596 mm
Width (base) (b) :
242 mm
Heigth (base) (g) :
44 mm
Hight (W) :
535 mm
Weight :
106.0 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Plummer Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Number of mounting holes (n),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - P32+02 B 607 Split Bearing Units Advantages and Applications
QIBR - P32+02 B 607 Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
