SDC3164+01 B 300M
- Inner diameter:
- 300 mm
- Mass:
- 208 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - SDC3164+01 B 300M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
SDC3164
Bearing model :
01 B 300M
Inner diameter (d) :
300 mm
Distance shaft axis (H) :
320 mm
MIN distance fixing bore (E) :
742 mm
MAX distance fixing bore (E) :
758 mm
Distance fixing bore (S) :
200 mm
Bolt size :
M36
Length total (a) :
880 mm
Width (base) (b) :
320 mm
Heigth (base) (g) :
60 mm
Hight (W) :
663 mm
Housing width (L) :
216 mm
Housing width (LI) :
248 mm
Housing weight :
208 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Interchangeable Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - SDC3164+01 B 300M Split Bearing Units Advantages and Applications
QIBR - SDC3164+01 B 300M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
