SDC3160+01 B 280M
- Inner diameter:
- 280 mm
- Mass:
- 175 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - SDC3160+01 B 280M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
SDC3160
Bearing model :
01 B 280M
Inner diameter (d) :
280 mm
Distance shaft axis (H) :
300 mm
MIN distance fixing bore (E) :
702 mm
MAX distance fixing bore (E) :
718 mm
Distance fixing bore (S) :
190 mm
Bolt size :
M36
Length total (a) :
830 mm
Width (base) (b) :
310 mm
Heigth (base) (g) :
55 mm
Hight (W) :
611 mm
Housing width (L) :
204 mm
Housing width (LI) :
232 mm
Housing weight :
175 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Interchangeable Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - SDC3160+01 B 280M Split Bearing Units Advantages and Applications
QIBR - SDC3160+01 B 280M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
