SDC3156+01 B 260M
- Inner diameter:
- 260 mm
- Mass:
- 160 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - SDC3156+01 B 260M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
SDC3156
Bearing model :
01 B 260M
Inner diameter (d) :
260 mm
Distance shaft axis (H) :
280 mm
MIN distance fixing bore (E) :
662 mm
MAX distance fixing bore (E) :
678 mm
Distance fixing bore (S) :
160 mm
Bolt size :
M36
Length total (a) :
790 mm
Width (base) (b) :
280 mm
Heigth (base) (g) :
55 mm
Hight (W) :
591 mm
Housing width (L) :
204 mm
Housing width (LI) :
232 mm
Housing weight :
160 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Interchangeable Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - SDC3156+01 B 260M Split Bearing Units Advantages and Applications
QIBR - SDC3156+01 B 260M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
