SDC3134+01 B 150M
- Inner diameter:
- 150 mm
- Mass:
- 48 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - SDC3134+01 B 150M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
SDC3134
Bearing model :
01 B 150M
Inner diameter (d) :
150 mm
Distance shaft axis (H) :
170 mm
MIN distance fixing bore (E) :
424 mm
MAX distance fixing bore (E) :
436 mm
Distance fixing bore (S) :
100 mm
Bolt size :
M24
Length total (a) :
510 mm
Width (base) (b) :
178 mm
Heigth (base) (g) :
41 mm
Hight (W) :
401 mm
Housing width (L) :
174 mm
Housing width (LI) :
174 mm
Housing weight :
48 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Interchangeable Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Distance shaft axis (H),
MIN distance fixing bore (E),
MAX distance fixing bore (E),
Distance fixing bore (S),
Bolt size,
Length total (a),
Width (base) (b),
Heigth (base) (g),
Hight (W),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - SDC3134+01 B 150M Split Bearing Units Advantages and Applications
QIBR - SDC3134+01 B 150M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
