01 H 120M+01 B 120M EX
- Inner diameter:
- 120 mm
- Mass:
- 22.3 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - 01 H 120M+01 B 120M EX
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
01 H 120M
Bearing model :
01 B 120M EX
Inner diameter (d) :
120 mm
Diameter of housing abutment (Db MAX) :
276 mm
Housing width (L) :
162 mm
Distance shaft axis (H) :
156 mm
Bolt size :
M36
Length of housing fixed end (Y) :
76 mm
Distance guidance grooves (e) :
238 mm
Weight :
22.3 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Hanger Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Diameter of housing abutment (Db MAX),
Housing width (L),
Distance shaft axis (H),
Bolt size,
Length of housing fixed end (Y),
Distance guidance grooves (e),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Diameter of housing abutment (Db MAX),
Housing width (L),
Distance shaft axis (H),
Bolt size,
Length of housing fixed end (Y),
Distance guidance grooves (e),
Weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - 01 H 120M+01 B 120M EX Split Bearing Units Advantages and Applications
QIBR - 01 H 120M+01 B 120M EX Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
