F37+02 B 280M
- Inner diameter:
- 280 mm
- Mass:
- 195.0 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - F37+02 B 280M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
F37
Bearing model :
01 B 280M
Inner diameter (d) :
280 mm
Hight (W) :
762 mm
Number of mounting holes (n) :
8
Bolt size :
M30
Thickness of flange (k) :
38 mm
Distance shaft axis (H) :
159 mm
Shell hole diameter (N) :
603.25 mm
Shell hole depth (V) :
5 mm
Housing width (L) :
291 mm
Housing width (LI) :
309 mm
Housing weight :
195.0 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Flanged Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Number of mounting holes (n),
Bolt size,
Thickness of flange (k),
Distance shaft axis (H),
Shell hole diameter (N),
Shell hole depth (V),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Number of mounting holes (n),
Bolt size,
Thickness of flange (k),
Distance shaft axis (H),
Shell hole diameter (N),
Shell hole depth (V),
Housing width (L),
Housing width (LI),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - F37+02 B 280M Split Bearing Units Advantages and Applications
QIBR - F37+02 B 280M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
