DF02+01E B 50M
- Inner diameter:
- 50 mm
- Mass:
- 4.0 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - DF02+01E B 50M
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Metric
Housing model :
DF02
Bearing model :
01E B 50M
Inner diameter (d) :
50 mm
Hight (W) :
165 mm
Bolt size :
M12
Distance fixing bore (E) :
114 mm
Hexagon socket bolt size :
1/2 inch
Hexagon socket bolt F center distance :
118 mm
Distance shaft axis (H) :
52 mm
Shell hole diameter (N) :
120 mm
Thickness of flange (k) :
13 mm
Housing width (L) :
101 mm
Housing weight :
4.0 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Flanged Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Bolt size,
Distance fixing bore (E),
Hexagon socket bolt size,
Hexagon socket bolt F center distance,
Distance shaft axis (H),
Shell hole diameter (N),
Thickness of flange (k),
Housing width (L),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Bolt size,
Distance fixing bore (E),
Hexagon socket bolt size,
Hexagon socket bolt F center distance,
Distance shaft axis (H),
Shell hole diameter (N),
Thickness of flange (k),
Housing width (L),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - DF02+01E B 50M Split Bearing Units Advantages and Applications
QIBR - DF02+01E B 50M Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
