DF04+01E B 215
- Inner diameter:
- 2 15/16 inch
- Mass:
- 8.5 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - DF04+01E B 215
Brand :
QIBR
Rolling element type :
Roller
Measurement system :
Imperial
Housing model :
DF04
Bearing model :
01E B 215
Inner diameter (d) :
2 15/16 inch
Hight (W) :
217 mm
Bolt size :
M20
Distance fixing bore (E) :
164 mm
Hexagon socket bolt size :
3/4 inch
Hexagon socket bolt F center distance :
171 mm
Distance shaft axis (H) :
60 mm
Shell hole diameter (N) :
178 mm
Thickness of flange (k) :
16 mm
Housing width (L) :
117 mm
Housing weight :
8.5 kg
Ring material :
Bearing steel GCr15
Rolling element material :
Bearing steel GCr15
Number of rolling element rows :
Single Row
Bearing Type :
Flanged Bearing Units
Lubrication :
Grease
Bearing clearances :
CN/C2/C3
Temperature :
-30 ℃ to +110 ℃
Seal type :
Closed Type
Description
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Bolt size,
Distance fixing bore (E),
Hexagon socket bolt size,
Hexagon socket bolt F center distance,
Distance shaft axis (H),
Shell hole diameter (N),
Thickness of flange (k),
Housing width (L),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
Housing model,
Bearing model,
Inner diameter (d),
Hight (W),
Bolt size,
Distance fixing bore (E),
Hexagon socket bolt size,
Hexagon socket bolt F center distance,
Distance shaft axis (H),
Shell hole diameter (N),
Thickness of flange (k),
Housing width (L),
Housing weight,
Ring material,
Rolling element material,
Number of rolling element rows,
Bearing Type,
Lubrication,
Bearing clearances,
QIBR - DF04+01E B 215 Split Bearing Units Advantages and Applications
QIBR - DF04+01E B 215 Split Bearing Units Characteristics
Features & Benefits
Split Bearing Units revolutionize industrial maintenance by combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks) into a single, easy-to-install system. Designed for heavy-duty applications, they eliminate the need for complete shaft disassembly, drastically reducing downtime.
