Search for the bearing model you need
Standard
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh
Inner diameter (di)
120mm-8000mm
Outer diameter
280mm-8000mm
Weight
20kg-8000kg
Structures
Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Brand
QIBR/OEM/Neutral
Package
Standard Export Package
Material
42CrMo, 50Mn, or Stainless Steel
Applications
Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine
| NO. | Product | Product Number | Gear type | Inner diameter (Di) | Outer diameter (Da) | Overall height (H) | Weight |
|---|---|---|---|---|---|---|---|
| 1 |
|
230.20.0400.013 Typ 21/520.0 | No Gear | 304 mm | 518 mm | 56 mm | 23.4 kg |
| 2 |
|
230.20.0500.013 Typ 21/650.0 | No Gear | 434 mm | 648 mm | 56 mm | 31 kg |
| 3 |
|
230.20.0600.013 Typ 21/750.0 | No Gear | 534 mm | 748 mm | 56 mm | 36.4 kg |
| 4 |
|
230.20.0700.013 Typ 21/850.0 | No Gear | 634 mm | 848 mm | 56 mm | 42.8 kg |
| 5 |
|
230.20.0800.013 Typ 21/950.0 | No Gear | 734 mm | 948 mm | 56 mm | 47.8 kg |
| 6 |
|
230.20.0900.013 Typ 21/1050.0 | No Gear | 834 mm | 1048 mm | 56 mm | 53.1 kg |
| 7 |
|
230.20.1000.013 Typ 21/1200.0 | No Gear | 984 mm | 1198 mm | 56 mm | 61.9 kg |
| 8 |
|
231.20.0400.013 Typ 21/520.1 | No Gear | 304 mm | 504.4 mm | 56 mm | 29.3 kg |
| 9 |
|
231.20.0500.013 Typ 21/650.1 | No Gear | 434 mm | 640.8 mm | 56 mm | 39.5 kg |
| 10 |
|
231.20.0600.013 Typ 21/750.1 | No Gear | 534 mm | 742.8 mm | 56 mm | 47.6 kg |
| 11 |
|
231.20.0700.013 Typ 21/850.1 | No Gear | 634 mm | 838.8 mm | 56 mm | 53.5 kg |
| 12 |
|
231.20.0800.013 Typ 21/950.1 | No Gear | 734 mm | 950.4 mm | 56 mm | 65.1 kg |
| 13 |
|
231.20.0900.013 Typ 21/1050.1 | No Gear | 834 mm | 1046.4 mm | 56 mm | 69.6 kg |
| 14 |
|
231.20.1000.013 Typ 21/1200.1 | No Gear | 984 mm | 1198.4 mm | 56 mm | 83 kg |
| 15 |
|
232.20.0400.013 Typ 21/520.2 | No Gear | 326.5 mm | 518 mm | 56 mm | 27.1 kg |
| 16 |
|
232.20.0500.013 Typ 21/650.2 | No Gear | 445.2 mm | 648 mm | 56 mm | 36.9 kg |
| 17 |
|
232.20.0600.013 Typ 21/750.2 | No Gear | 547.2 mm | 748 mm | 56 mm | 43.7 kg |
| 18 |
|
232.20.0700.013 Typ 21/850.2 | No Gear | 649.2 mm | 848 mm | 56 mm | 51.1 kg |
| 19 |
|
232.20.0800.013 Typ 21/950.2 | No Gear | 737.6 mm | 948 mm | 56 mm | 61.6 kg |
| 20 |
|
232.20.0900.013 Typ 21/1050.2 | No Gear | 841.6 mm | 1048 mm | 56 mm | 65.8 kg |
| 21 |
|
232.20.1000.013 Typ 21/1200.2 | No Gear | 985.6 mm | 1198 mm | 56 mm | 80.7 kg |
| 22 |
|
230.20.0400.503 Typ 21/520.0 | No Gear | 304 mm | 518 mm | 56 mm | 23 kg |
| 23 |
|
230.20.0500.503 Typ 21/650.0 | No Gear | 434 mm | 648 mm | 56 mm | 30.4 kg |
| 24 |
|
230.20.0600.503 Typ 21/750.0 | No Gear | 534 mm | 748 mm | 56 mm | 35.8 kg |
| 25 |
|
230.20.0700.503 Typ 21/850.0 | No Gear | 634 mm | 848 mm | 56 mm | 42.2 kg |
| 26 |
|
230.20.0800.503 Typ 21/950.0 | No Gear | 734 mm | 948 mm | 56 mm | 47.1 kg |
| 27 |
|
230.20.0900.503 Typ 21/1050.0 | No Gear | 834 mm | 1048 mm | 56 mm | 52.3 kg |
| 28 |
|
230.20.1000.503 Typ 21/1200.0 | No Gear | 984 mm | 1198 mm | 56 mm | 61.1 kg |
| 29 |
|
231.20.0400.503 Typ 21/520.1 | No Gear | 304 mm | 504.4 mm | 56 mm | 29.0 kg |
| 30 |
|
231.20.0500.503 Typ 21/650.1 | No Gear | 434 mm | 640.8 mm | 56 mm | 39.2 kg |
| 31 |
|
231.20.0600.503 Typ 21/750.1 | No Gear | 534 mm | 742.8 mm | 56 mm | 47.2 kg |
| 32 |
|
231.20.0700.503 Typ 21/850.1 | No Gear | 634 mm | 838.8 mm | 56 mm | 53.1 kg |
| 33 |
|
231.20.0800.503 Typ 21/950.1 | No Gear | 734 mm | 950.4 mm | 56 mm | 64.7 kg |
| 34 |
|
231.20.0900.503 Typ 21/1050.1 | No Gear | 834 mm | 1046.4 mm | 56 mm | 69.1 kg |
| 35 |
|
231.20.1000.503 Typ 21/1200.1 | No Gear | 984 mm | 1198.4 mm | 56 mm | 82.5 kg |
| 36 |
|
232.20.0400.503 Typ 21/520.2 | No Gear | 326.5 mm | 518 mm | 56 mm | 26.9 kg |
| 37 |
|
232.20.0500.503 Typ 21/650.2 | No Gear | 445.2 mm | 648 mm | 56 mm | 36.7 kg |
| 38 |
|
232.20.0600.503 Typ 21/750.2 | No Gear | 547.2 mm | 748 mm | 56 mm | 43.4 kg |
| 39 |
|
232.20.0700.503 Typ 21/850.2 | No Gear | 649.2 mm | 848 mm | 56 mm | 50.8 kg |
| 40 |
|
232.20.0800.503 Typ 21/950.2 | No Gear | 737.6 mm | 948 mm | 56 mm | 61.3 kg |
| 41 |
|
232.20.0900.503 Typ 21/1050.2 | No Gear | 841.6 mm | 1048 mm | 56 mm | 65.4 kg |
| 42 |
|
232.20.1000.503 Typ 21/1200.2 | No Gear | 985.6 mm | 1198 mm | 56 mm | 80.3 kg |
| 43 |
|
230.21.0475.013 Typ 21/520.0 | No Gear | 305 +0.08 mm | 517 -0.11 mm | 56 mm | 23.4 kg |
| 44 |
|
230.21.0575.013 Typ 21/650.0 | No Gear | 435 +0.10 mm | 647 -0.13 mm | 56 mm | 31 kg |
| 45 |
|
230.21.0675.013 Typ 21/750.0 | No Gear | 535 +0.11 mm | 747 -0.13 mm | 56 mm | 36.4 kg |
| 46 |
|
230.21.0775.013 Typ 21/850.0 | No Gear | 635 +0.13 mm | 847 -0.14 mm | 56 mm | 42.8 kg |
| 47 |
|
230.21.0875.013 Typ 21/950.0 | No Gear | 735 +0.13 mm | 947 -0.14 mm | 56 mm | 47.8 kg |
| 48 |
|
230.21.0975.013 Typ 21/1050.0 | No Gear | 835 +0.14 mm | 1047 -0.17 mm | 56 mm | 53.1 kg |
| 49 |
|
230.21.1075.013 Typ 21/1200.0 | No Gear | 985 +0.14 mm | 1197 -0.17 mm | 56 mm | 61.9 kg |
| 50 |
|
231.21.0475.013 Typ 21/520.1 | No Gear | 305 +0.08 mm | 504.8 mm | 56 mm | 29.3 kg |
| 51 |
|
231.21.0575.013 Typ 21/650.1 | No Gear | 435 +0.10 mm | 640.8 mm | 56 mm | 39.5 kg |
