AISI 440C Stainless Steel Ball 3 1/2inch
- Outer diameter:
- 3.50000 inch
- Mass:
- 2935.66699 g
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - AISI 440C Stainless Steel Ball 3 1/2inch
Brand :
QIBR
Measurement system :
Imperial
Nominal diameter (Dw) :
3.50000 inch
Mass :
2935.66699 g
Material :
AISI 440C
Ball diameter tolerance :
-0.000354" to 0.000354"
Density :
7.75 g/cm3
MAX temperature :
800° F | 427℃
Hardness :
60-65 HRC
Magnetic properties :
Magnetic
Molybdenum :
0.4-0.75%
Carbon :
0.95-1.2%
Chromium :
16-18%
Copper :
0-0.5%
Manganese :
0-1%
Nickel :
0-0.75%
Phosphorus :
0-0.04%
Iron :
76.73-82.65%
Silicon :
0-1%
Sulfur :
0-0.03%
Heat treatment :
Hardened
Tolerance :
Standard
Specifications met :
AMS 5630
Rohs :
Compliant
Description
Features & Benefits
This part with Bearing balls, Bearing rollers, Rail, Cross-Roller Guide, etc included.
304 stainless steel, 316 stainless steel, 440 stainless steel
