SBKH 12060-7.6

Outer diameter:
120 mm
Width:
308 mm
Mass:
53.7 kg

We will provide you with the most suitable solution.

SBKH 12060-7.6

Image may differ from product. See technical specification for details.

Specifications

Seris - SBKH 12060-7.6

Brand : QIBR
Rolling element type : Ball
Measurement system : Metric
Precision level : C7
Screw shaft outer diameter (d) : 120 mm
Lead (Ph) : 60 mm
Ball center-to-center diameter (dp) : 124.0 mm
Thread minor diameter (dc) : 103.6 mm
No. of loaded circuits rows X turns : 2X3.8
Basic load rating (Ca) : 962 KN
Basic load rating (Coa) : 2941 KN
Rigidity (K) : 4809 N/μm
Outer diameter (D) : 210 mm
Flange diameter (D1) : 288 mm
Overall length (L1) : 308 mm
H : 45 mm
B1 : 240 mm
PCD : 249 mm
d1 : 26 mm
N1 : 22.5 mm
Greasing hole (A) : PT 1/8
Nut mass : 53.7 kg
Shaft mass : 78.1 kg/m
Temperature : -15 ℃ to +80 ℃
Seal type : Open Type
SBKH 12060-7.6
Download SBKH 12060-7.6 Drawing

Description

Screw shaft outer diameter (d), Lead (Ph), Ball center-to-center diameter (dp), Thread minor diameter (dc), No. of loaded circuits rows X turns, Basic load rating (Ca), Basic load rating (Coa), Rigidity (K), Outer diameter (D), Flange diameter (D1), Overall length (L1), H, B1, PCD, d1, N1, Greasing hole (A), Nut mass, Shaft mass,

QIBR - SBKH 12060-7.6 Machine Element Advantages and Applications

SBKH 12060-7.6 Machine Element, high speed, high repeated positioning accuracy, Screw shaft outer diameter (d) is 120 mm ，Outer diameter (D) is 210 mm，Overall length (L1) is 308 mm， suitable for precision surgical robots, CNC milling machines, wind turbines and conveyor belts, etc., and is the most widely used bearing in working conditions requiring high positioning accuracy.

Screw shaft outer diameter (d), Lead (Ph), Ball center-to-center diameter (dp), Thread minor diameter (dc), No. of loaded circuits rows X turns, Basic load rating (Ca), Basic load rating (Coa), Rigidity (K), Outer diameter (D), Flange diameter (D1), Overall length (L1), H, B1, PCD, d1, N1, Greasing hole (A), Nut mass, Shaft mass,

QIBR - SBKH 12060-7.6 Machine Element Characteristics

SBKH 12060-7.6 Machine Element, low running noise, easy installation. SBKH 12060-7.6 Machine Element, can bear radial load and axial load at the same time, suitable for mechanical equipment with high speed requirements.

SBKH 12060-7.6 Ball Screw Product Features and Advantages

Low friction: Rolling friction is adopted, friction loss is reduced, and higher transmission efficiency is achieved.

High precision: Provides good repeat positioning accuracy, suitable for applications requiring high-precision motion control.

Strong load capacity: Able to withstand large loads, maintain stable motion performance under high loads, suitable for heavy load applications.

Smooth motion: Able to achieve smooth linear motion during operation, reducing vibration and noise.

Application: Widely used in high-precision CNC machine tools, robot joint drives, medical equipment, measuring instruments, electronic equipment, aerospace and other fields.

QIBR - SBKH 12060-7.6 Ball Screw Optimization

Adjustable Dimensions: The screw shaft's terminal end is unprocessed, allowing for additional machining to customize the shape and size according to the customer's ball screw requirements.

Process Optimization: The geometry of the threads and balls is optimized to increase contact area and load capacity.

Further Customization:QIBR can design and optimize ball screws according to customer drawings and operating conditions.

More customization: QIBR can design and optimize the ball screw according to customer requirements for drawings and ball screw working conditions.

QIBR - SBKH 12060-7.6 Ball Screw Quality Control

Dimension measurement: Use a variety of professional high-precision instruments to measure multiple dimensions of the ball screw, with a maximum accuracy of 0.001mm.

Hardness measurement: Use a hardness tester to measure the surface hardness of the guide rail, with a measurement accuracy of ±0.5HRC.

Roughness measurement: Use a surface roughness meter to measure the surface roughness of the ball screw, with a maximum accuracy of ±0.01μm.

Load measurement: A load is applied using a force sensor, and the deformation of the ball screw is measured with a micrometer.

Geometric tolerance: Use a profiler to measure the geometric shape and relative position of the ball screw.

Raw material control: Procurement of steel and parts from ISO 14001 certified suppliers ensures product stability while promoting sustainable development.

Features & Benefits

This part with Bearing balls, Bearing rollers, Rail, Cross-Roller Guide, etc included.
SBKH 12060-7.6
The screw is the main part of the ball screw, usually made of metal material, with a thread structure. The thread on the screw is usually a triangular thread, which is used to contact the balls inside the ball screw bearing, and generate a driving force when the screw is turned, thereby achieving linear motion.
The nut is a part that matches the screw, usually made of metal, with a thread structure inside that matches the screw thread. There is also a guide groove inside the nut for accommodating the ball.
