S6108

Part number
S6108
Pitch (DP)
6
Number of teeth (z)
108

We will provide you with the most suitable solution.

S6108

Image may differ from product. See technical specification for details.

Specifications

Seris - S6108

Brand : QIBR
Part number : S6108
Pitch (DP) : 6
Number of teeth (z) : 108
Pressure angle : 14 1/2 °
Pitch diameter : 18.000 inch
Outer diameter (D) : 18.333 inch
Inner diameter (d) : 1 1/4~2 13/16 inch
Gear tooth width (b) : 1 1/2 inch
Hub diameter (H) : 5 1/8 inch
Hub protract (P) : 1 1/4 inch
Weight : 53.00 lbs
S6108
Download S6108 Drawing

Description

Part number, Pitch (DP), Number of teeth (z), Pressure angle, Pitch diameter, Outer diameter (D), Inner diameter (d), Gear tooth width (b), Hub diameter (H), Hub protract (P), Weight,

QIBR - S6108 Gears Advantages and Applications

S6108 Gears, simple structure, high precision, high load-bearing capacity, Pitch (DP) is 6, Outer diameter (D) is 18.333 inch, Weight is 53.00 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Part number, Pitch (DP), Number of teeth (z), Pressure angle, Pitch diameter, Outer diameter (D), Inner diameter (d), Gear tooth width (b), Hub diameter (H), Hub protract (P), Weight,

QIBR - S6108 Gears Characteristics

S6108 Gears, high reliability, long life, easy installation and maintenance. S6108 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.

Features & Benefits

Gears are important components in mechanical transmission, transmitting power and motion through the meshing of teeth. Widely used in fields such as clocks, automobiles, industrial equipment, etc., it has the characteristics of precise transmission, high efficiency and stability.
S6108
