S5120

Part number
S5120
Pitch (DP)
5
Number of teeth (z)
120

We will provide you with the most suitable solution.

S5120

Image may differ from product. See technical specification for details.

Specifications

Seris - S5120

Brand : QIBR
Part number : S5120
Pitch (DP) : 5
Number of teeth (z) : 120
Pressure angle : 14 1/2 °
Pitch diameter : 24.000 inch
Outer diameter (D) : 24.400 inch
Inner diameter (d) : 1 5/16~3 1/2 inch
Gear tooth width (b) : 1 3/4 inch
Hub diameter (H) : 6 1/8 inch
Hub protract (P) : 1 1/2 inch
Weight : 113.00 lbs
S5120
Download S5120 Drawing

Description

Part number, Pitch (DP), Number of teeth (z), Pressure angle, Pitch diameter, Outer diameter (D), Inner diameter (d), Gear tooth width (b), Hub diameter (H), Hub protract (P), Weight,

QIBR - S5120 Gears Advantages and Applications

S5120 Gears, simple structure, high precision, high load-bearing capacity, Pitch (DP) is 5, Outer diameter (D) is 24.400 inch, Weight is 113.00 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Part number, Pitch (DP), Number of teeth (z), Pressure angle, Pitch diameter, Outer diameter (D), Inner diameter (d), Gear tooth width (b), Hub diameter (H), Hub protract (P), Weight,

QIBR - S5120 Gears Characteristics

S5120 Gears, high reliability, long life, easy installation and maintenance. S5120 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.

Features & Benefits

Gears are important components in mechanical transmission, transmitting power and motion through the meshing of teeth. Widely used in fields such as clocks, automobiles, industrial equipment, etc., it has the characteristics of precise transmission, high efficiency and stability.
S5120
