C532

Part number: C532

Pitch (DP): 5

Number of teeth (z): 32

We will provide you with the most suitable solution.

Image may differ from product. See technical specification for details.

Brand : QIBR

Part number : C532

Pitch (DP) : 5

Number of teeth (z) : 32

Pressure angle : 14 1/2 °

Pitch diameter : 6.400 inch

Outer diameter (D) : 6.800 inch

Inner diameter (d) : 1 1/16~2 1/16 inch

Gear tooth width (b) : 1 3/4 inch

Hub diameter (H) : 3 1/4 inch

Hub protract (P) : 1 1/4 inch

Weight : 13.50 lbs

Download C532 Drawing

QIBR - C532 Gears Advantages and Applications

C532 Gears, simple structure, high precision, high load-bearing capacity, Pitch (DP) is 5, Outer diameter (D) is 6.800 inch, Weight is 13.50 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

QIBR - C532 Gears Characteristics

C532 Gears, high reliability, long life, easy installation and maintenance. C532 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.

Features & Benefits

Gears are important components in mechanical transmission, transmitting power and motion through the meshing of teeth. Widely used in fields such as clocks, automobiles, industrial equipment, etc., it has the characteristics of precise transmission, high efficiency and stability.
